Rear & side-return extension
Rear and side-return extension to a Victorian terrace, Hampstead
A single-storey brick and slim-framed glazed side-return infill to a four-storey red-brick Victorian terrace in NW3, stepped behind the rear outrigger line to protect neighbour daylight and garden character.
- Project type
- Rear & side-return extension
- Area
- Hampstead, London
- Planning authority
- Camden
- Constraint
- Hampstead Conservation Area with Article 4 direction
- Application type
- Householder planning application
- Decision
- Approved with conditions — August 2026
The property, planning constraint & architectural outcome
The property is a four-storey Victorian terrace within the Hampstead Conservation Area, where an Article 4 direction withdraws permitted development rights for rear and side alterations facing shared gardens. The original ground-floor plan separated a narrow rear kitchen in the outrigger from the front reception rooms, leaving a damp side return and a stepped threshold down to the garden.
Our measured survey established the neighbouring outrigger projections, boundary wall heights and 45-degree daylight angles to adjoining ground-floor windows. Rather than pushing beyond the established rear building line, the design infills the side return with a sloped lead-and-glass roof set below the existing party-wall parapet and steps the rear elevation back by 300mm from the adjoining outrigger.
Materials were specified to match the host terrace: reclaimed London stock and red multi brickwork laid in lime mortar, a yorkstone coping along the boundary parapet, and dark bronze-anodised aluminium glazing frames with slim sightlines. A green sedum roof over the flat rear portion satisfied Camden policy on urban greening and surface-water attenuation.
Camden granted householder planning permission subject to standard materials and tree-protection conditions. The technical Building Regulations and structural steelwork package followed immediately, coordinating a concealed cranked box-frame so the internal ceiling plane runs flush from the dining room to the garden threshold.
Following planning approval, our in-house structural engineers and architectural team produced the coordinated RIBA Stage 4 Building Regulations and structural steelwork package, working alongside our sister companies Hampstead Chartered Surveyors & Building Consultancy (Party Wall awards with both adjoining owners) and Hampstead Renovations.
Key planning & technical takeaways
- Early 3D laser scanning of neighbouring outriggers and boundary walls established an indisputable 45-degree daylight envelope before pre-application submission.
- Setting the rear extension 300mm behind the adjoining outrigger and using a dark bronze-anodised slim-frame glazing profile satisfied the Hampstead Conservation Area appraisal.
- Integrating structural goal-post steelwork within the existing first-floor floor zone avoided any downstand beam interrupting the flush ceiling plane.
